System x NetBAY S2 42U Standard Rack Cabinet

S2 42U Standard Rack Cabinet, Black - includes Side Panels


External dimensions :
Height: 1999 mm (78.7 in)
Width: 605 mm (23.8 in)
Depth: 1001 mm (39.4 in)
Weight: 124.7 kg (275 lb)

Internal dimensions :
Height: 1870 mm (73.6 in)
Width: 450 mm (17.7 in)
Depth: 865 mm (34.0 in) — Frame
Depth: 719 mm (28.3 in) — Front-to-rear mounting flanges

Load carrying capacity :
Empty cabinet: 124.7 kg (275 lb)
Load capacity: 907.2 kg (1996 lb)
Total: 1031.9 kg (2275 lb)

Value-priced rack for entry-level and midrange rack solutions
The 42U Rack is less than 2 meters in height allowing the rack to fit under most doorways
Six sidewall compartments support installation of 1U power distribution units (PDUs) and switches without unnecessarily taking up valuable rack space
Support full density of all IBM System x™ servers by improved air flow allowing for a fan-free rack environment
Lockable doors and side walls provide a more secure environment for equipment and data
The S2 Rack family can accommodate a single installation or hundreds of rack enabled products and can be easily deployed while at the same time offer a very competitive value to our customers
External dimensions (HxWxD): 200x61x100cm (78.7"x24"x39.4") 93074XX IBM 42U S2 Expansion Rack ships without side panels and includes baying kits and is intended to be used in conjunction with the 93074RX IBM 42U S2 Standard Rack when creating a suite of racks
